Add a rose diagram of heading angles to a radiate plot

Source: R/circular_plotting.R
add_angle_rose.Rd

Draws angular frequency as filled wedge polygons in the Cartesian coordinate space used by radiate. Each wedge spans one angular bin; its outer radius is proportional to the proportion (or count) of frames in that bin. The layer can be faceted by passing the same column used in the parent radiate(panel_by = ...) call.

Usage

add_angle_rose(
  hd,
  bins = 12L,
  angle_col = "heading",
  group_col = NULL,
  scale = 0.4,
  inner_r = 0,
  normalize = TRUE,
  fill = "steelblue",
  colour = NA,
  alpha = 0.5,
  arc_pts = 20L,
  display = NULL
)

Arguments

hd

Data frame of headings, e.g. from pose_to_headings or derive_headings(..., frame_select = "all").

bins

Integer; number of equal angular sectors. Default 12.

angle_col

Column containing headings in radians. Default "heading".

group_col

Column used for faceting; must match the panel_by argument of the parent radiate() call.

scale

Maximum outer radius of the tallest wedge as a fraction of the unit circle radius. Default 0.4.

inner_r

Inner radius of wedges. Default 0; set > 0 for a donut style.

normalize

TRUE (default) scales wedges by proportion; FALSE uses raw counts.

fill

Wedge fill colour. Default "steelblue".

colour

Wedge border colour. Default NA (no border).

alpha

Opacity. Default 0.5.

arc_pts

Points used to approximate each wedge arc. Default 20L.

display

A `circ_display()` controlling rotation, matching the parent `radiate()` plot. Default `NULL` uses the input's `display` attribute when present, otherwise the identity display.

Value

A geom_polygon layer that can be added to a radiate() plot with +.
