Make ggplot object of tracks radiating from circle centre.

Accepts either a precomputed data frame of polar/cartesian coordinates or a `Tracks`. When a `Tracks` is supplied, column mappings are inferred from the object and handed off to the plotting helpers.

Usage

radiate(data, ...)

# S3 method for class 'Tracks'
radiate(data, ...)

# Default S3 method
radiate(
  data,
  x_col = "rel_x",
  y_col = "rel_y",
  geom = "path",
  group_col = NULL,
  colour_col = NULL,
  colour_cycle = NULL,
  track_colour = c("trajectory", "sequence", "time", "speed"),
  time_units = c("seconds", "minutes", "milliseconds"),
  coords = c("relative", "absolute"),
  facets = NULL,
  rows = NULL,
  cols = NULL,
  ncol = NULL,
  strip_labels = NULL,
  strip_position = c("top", "bottom", "left", "right", "inside"),
  strip_label_size = 11,
  ticks = NULL,
  degrees = NULL,
  legend = NULL,
  title = NULL,
  xlab = NULL,
  ylab = NULL,
  axes = NULL,
  angle_labels = c("degrees", "none", "radians", "cardinal", "hours", "months",
    "seconds"),
  angle_label_position = c("outside", "inside", "split"),
  angle_label_outer_radius = NULL,
  n_labels = NULL,
  theme = c("void", "minimal", "classic", "bw", "grey", "gray", "light", "dark",
    "linedraw"),
  quadrants = FALSE,
  rings = FALSE,
  grid = c("radial", "cartesian", "none"),
  grid_colour = NULL,
  origin = FALSE,
  circumference = TRUE,
  show_labels = NULL,
  label_col = NULL,
  label_size = 3,
  label_padding = 1.08,
  label_use_repel = TRUE,
  show_tracks = TRUE,
  clip_tracks = TRUE,
  show_arrow = NULL,
  arrow_angle_col = NULL,
  arrow_colour = "black",
  arrow_colour_col = NULL,
  arrow_size = 2,
  display = circ_display(),
  ...,
  color_col = NULL,
  color_cycle = NULL,
  track_color = NULL,
  grid_color = NULL,
  arrow_color = NULL,
  arrow_color_col = NULL
)

# S3 method for class 'headings_frame'
radiate(
  data,
  col = NULL,
  step = 0.025,
  start_sep = step/2,
  tol = NULL,
  direction = "inward",
  base_r = 1,
  shade = FALSE,
  shape = FALSE,
  facets = NULL,
  ncol = NULL,
  ticks = TRUE,
  degrees = TRUE,
  angle_labels = c("degrees", "none", "radians", "cardinal", "hours", "months",
    "seconds"),
  angle_label_position = c("outside", "inside", "split"),
  angle_label_outer_radius = NULL,
  n_labels = NULL,
  title = NULL,
  theme = c("void", "minimal", "classic", "bw", "grey", "gray", "light", "dark",
    "linedraw"),
  quadrants = FALSE,
  rings = FALSE,
  grid = c("radial", "cartesian", "none"),
  grid_colour = NULL,
  circumference = TRUE,
  origin = FALSE,
  colour_col = NULL,
  legend = FALSE,
  display = circ_display(),
  show_markers = TRUE,
  ...
)

Arguments

data: Data frame or `Tracks`.
...: Additional arguments forwarded to [draw_tracks()].
x_col: Name of the x-coordinate column. Default "rel_x".
y_col: Name of the y-coordinate column. Default "rel_y".
geom: Geom specification passed to [draw_tracks()].
group_col: Optional column for grouping aesthetics.
colour_col, color_col: Optional column for colour aesthetics. Mutually exclusive with `colour_cycle`. `color_col` is the American-spelling alias.
colour_cycle, color_cycle: Optional cycling colour specification. Either a positive integer `n` (trajectories are assigned colours 1–n, cycling back to 1 after every `n` trajectories) or a character vector of colour values (e.g. `c("red","blue","green")`). When `facets` is set the cycle restarts independently within each panel. Mutually exclusive with `colour_col`. `color_cycle` is the American-spelling alias.
track_colour, track_color: How trajectory paths are coloured. `"trajectory"` (default) keeps the existing per-track colouring. `"sequence"` colours each path by its point's normalized position from start (0) to finish (1) within the track, applying a continuous viridis scale with a `"start -> finish"` colourbar. `"time"` colours each path by real elapsed time from its own track's start (see [elapsed_seconds()]), applying a continuous viridis scale with an `"elapsed (s)"` colourbar; numeric (frame) time requires a [frame_rate()] (set one with `set_frame_rate(ts, fps)`). `"speed"` colours each path by its instantaneous speed (see [instantaneous_speed()]), applying a continuous viridis scale with a `"speed (units/s)"` colourbar; numeric (frame) time likewise requires a [frame_rate()]. `"sequence"`, `"time"`, and `"speed"` own the colour aesthetic and so cannot be combined with `colour_col`/`colour_cycle`; overlays render in a fixed colour. The per-track order is taken from the `Tracks` time column, falling back to row order (with a message) when no usable time column is present. `track_color` is the American-spelling alias.
time_units: Units for `track_colour = "time"`: `"seconds"` (default), `"minutes"`, or `"milliseconds"`. Sets the colourbar title and scale.
coords: Which reference frame to plot: `"relative"` (default) uses the landmark-relative position (`rel_x`/`rel_y`) and relative headings; `"absolute"` uses the unit-circle position (`x`/`y`) in the original (un-rotated) frame and absolute headings, useful as an experimental control. Ignored when explicit `x_col`/`y_col` are supplied. Errors if `"absolute"` is requested but the `Tracks` has no `x`/`y` columns registered.
facets: NULL, a column name, or a character vector of column names to facet by (via [ggplot2::facet_wrap()]). The named column(s) must be present in the data.
rows, cols: Optional character vectors of column names to facet into a row x column grid via [ggplot2::facet_grid()] (mirroring ggplot: `rows` and `cols` map to the two sides of the `rows ~ cols` formula, and multiple variables per side nest as in `facet_grid()`). Use these *or* `facets` (`facet_wrap`), not both. Scales are fixed (circular panels stay round); `ncol`/`strip_position = "inside"` apply to `facets` only.
ncol: Number of columns passed to [ggplot2::facet_wrap()] when `facets` is set.
strip_labels: Logical or `NULL`. Whether to show a label identifying the panel variable value on each panel. Defaults to `TRUE` when `facets` is set, `FALSE` otherwise. Ignored when `facets` is `NULL`.
strip_position: Position of the panel label. One of `"top"` (default), `"bottom"`, `"left"`, `"right"` (ggplot2 strip positions), or `"inside"` (places a text annotation inside the plot area, centred below the unit circle at y = -1.25).
strip_label_size: Font size for strip labels. Applies to both strip text and the in-panel `"inside"` annotation.
ticks, degrees, legend, title, xlab, ylab, axes: Additional styling options. `degrees` is retained for back-compatibility; `degrees = FALSE` is equivalent to `angle_labels = "none"`. Tick styling (colour, width, length) follows the chosen `theme`'s `axis.ticks`.
angle_labels: Circumference labels. `"degrees"` (default; e.g. `45°`), `"radians"` (e.g. `π/4`), or `"none"` use diagonal angle labels via [degree_labs()]. The domain scales `"cardinal"` (N/E/S/W), `"hours"` (24-hour clock), `"months"` (Jan...Dec), and `"seconds"` instead label the circumference via [circumference_labs()], aligning the tick count to the scale. For finer control (8-point compass, 12-hour clock, month formats) add an explicit `circumference_labs()` layer. Label styling follows the chosen `theme`'s `axis.text`.
angle_label_position: For the numeric (`"degrees"`/`"radians"`) labels, where to place them: `"outside"` (default) keeps the diagonals in the plot corners; `"inside"` puts all eight directions (including cardinals) just inside the circle; `"split"` puts the cardinals inside and the diagonals outside. Ignored by the domain scales (`"cardinal"`/`"hours"`/`"months"`/ `"seconds"`), which place labels via [circumference_labs()]. See [degree_labs()].
angle_label_outer_radius: Optional corner magnitude for the numeric diagonal labels (`"degrees"`/`"radians"`). `NULL` (default) keeps the standard position; a larger value pushes the labels outward to clear wide/stacked circumference overlays such as grouped circular boxplots.
n_labels: Number of equally-spaced circumference divisions (ticks and numeric labels) at `360 / n` degrees, for the numeric `"degrees"`/`"radians"` labels. `NULL` (default) keeps the standard 8 ticks and legacy label set; `0` draws a bare circle (no ticks or labels); e.g. `4` (cardinals), `12` (clock). Orthogonal to `angle_labels` (the format). Ignored by the domain scales (`"cardinal"`/`"hours"`/`"months"`/`"seconds"`), which carry their own count.
theme: Plot appearance, named for the ggplot2 base themes: one of `"void"` (default), `"minimal"`, `"classic"`, `"bw"`, `"grey"`, `"light"`, `"dark"`, or `"linedraw"`. See [radial_theme()].
quadrants: Logical; draw the two dashed lines through the origin that demarcate the quadrants. Default `FALSE`. Their colour and width follow the chosen `theme`'s grid lines (see [radial_theme()]).
rings: Logical; draw concentric guide rings (the radial analogue of a grid). Default `FALSE`. Their colour and width follow the chosen `theme`'s grid lines.
grid: One of `"radial"` (default), `"cartesian"`, or `"none"`. `"radial"` replaces the theme's Cartesian grid with theme-styled radial guides (circular disc + major/minor crosshairs and rings) for grid-bearing themes, and draws nothing for grid-less themes (`void`, `classic`). `"cartesian"` keeps the theme's square grid; `"none"` removes all gridlines.
grid_colour, grid_color: Optional colour overriding the theme-derived guide colour. `grid_color` is the American-spelling alias.
origin: Logical; draw a centre point. Default `FALSE`. When drawn it takes the theme's axis ink colour.
circumference: Logical; draw the unit-circle circumference as a fallback boundary when no radial grid marks it (grid-less themes, `grid = "none"`). Default `TRUE`. Styled from the theme's `axis.line` (else the axis ink). On grid-bearing themes the grid's outer ring marks the boundary instead, so this has no effect there.
show_labels: Whether to place labels at the circumference. When `TRUE` (default) and no `label_col` is given, `radiate()` falls back to the id/group column only if it has at most 12 distinct values, so many-track plots are not buried under per-trial id labels. Set `label_col` to force labelling regardless of track count.
label_col: Column containing label values. When supplied explicitly, labels are always drawn (the many-track guard applies only to the automatic fallback).
label_size: Text size for circumference labels.
label_padding: Multiplier applied to the unit circle when placing labels.
label_use_repel: Use `ggrepel::geom_text_repel()` when available.
show_tracks: Whether to draw the trajectory paths. Default `TRUE`. Set to `FALSE` to render the unit circle and any overlays (arrow, circle, ticks) without the track geometry.
clip_tracks: Logical; when `TRUE` (default) trajectory paths are clipped to the unit circle, so beyond-circumference (`rho > 1`) excursions are truncated at the circumference (segment-intercept, leaving a gap until the track re-enters) rather than drawn past it. Set `FALSE` to draw tracks unclipped. Plot-only: kinematics are unaffected. `rho` is unchanged by the relative-frame rotation, so this applies equally when `coords = "absolute"`.
show_arrow: Whether to draw a mean resultant arrow from the centre.
arrow_angle_col: Column containing angles (radians) to summarise for the arrow.
arrow_colour, arrow_color: Arrow colour (a single fixed colour). Ignored when `arrow_colour_col` is set. `arrow_color` is the American-spelling alias.
arrow_colour_col, arrow_color_col: Optional grouping column. When supplied, one mean resultant arrow is drawn per level of this column (within each panel, if `facets` is also set) and mapped to the colour aesthetic, so the arrow can follow a colour grouping independently of faceting. Default `NULL` draws a single arrow in `arrow_colour`. `arrow_color_col` is the American-spelling alias.
arrow_size: Arrow linewidth.
display: A [`circ_display`] object controlling how angles are rendered. Default `circ_display()` puts North at top with clockwise-positive degrees. Use `circ_display(zero = 0)` when the reference direction lies at East in unit-circle coordinates (e.g. the `cpunctatus` dataset).
col: Name of the angle column in data. Defaults to the heading_col attribute when data is a headings_frame.
step, start_sep, tol, direction, base_r, shade, shape: Passed to add_stacked_headings. See that function for details.
show_markers: When TRUE (default) the stacked-dot markers are drawn; FALSE returns the themed radial frame only, for callers that layer their own marker and statistic overlays.

Value

A `ggplot2` object.

American spellings

Every `colour...` argument and the `assign_colour_*` / `cycle_colours` / `hf_colour_col` functions accept the American `color...` spelling as an alias (e.g. `color`, `color_col`, `track_color`). British spelling is canonical; supplying both spellings of a pair is an error.

Examples

tracks_demo <- simulate_tracks(conditions = data.frame(n_trials = 1L),
                               n_points = 200, seed = 1)
radiate(tracks_demo, x_col = "rel_x", y_col = "rel_y", group_col = "trial_id")

radiate(cpunctatus, coords = "absolute")
#> Warning: Removed 105 rows containing missing values or values outside the scale range
#> (`geom_path()`).
